Enterovirus D68 returns to Europe

After its global emergence in 2014, subsequent outbreaks of enterovirus D68 occurred in 2016 and 2018. The expected outbreak of 2020 never materialized, likely due to masking and physical distancing put in place for the SARS-CoV-2 pandemic. As these measures are relaxed in multiple countries, increased in cases of respiratory virus infection have been observed, including enterovirus D68 in Europe.

A total of laboratory-confirmed 139 EV-D68 cases were identified between 31 July and 14 October 2021 in eight countries. The peak incidence was in September, in line with seasonal occurrence of enterovirus infections.  Most of the cases were in males (88/139; 63%) and mainly younger than 5 years of age (120/139; 86%), with a median age of 3 years. Clinical symptoms were reported for 120 cases; most exhibited respiratory symptoms. While neurological symptoms were present in five cases, none was diagnosed with AFP or acute flaccid myelitis (AFM).

The re-emergence of EV-D68 in Europe serves as a reminder that surveillance for this virus must continue. So far there have not been reported cases of EV-D68 infections in the United States or in other countries outside of Europe. With increased relaxation of distancing and masking measures, it is only a matter of time before EV-D68 infections and associated AFM return.

Update August 2021

Acute Flaccid Myelitis (AFM), associated with enterovirus D68 (EV-D68) infection, has become an epidemic. Until the summer of 2014 few cases of EV-D68 infections were diagnosed. Subsequently biennial outbreaks have occurred in 2016 and 2018; during which the number of confirmed cases of EV-D68 associated AFM has increased. At least 650 children in the United States have suffered some level of paralysis from AFM, often resulting in long-term physical deficits. Yet, many children and adults are infected with EV-D68 without developing AFM.

Many aspects of EV-D68 biology within the pediatric population remain unexplored including pressing questions about virion antigenicity, mechanisms of virus neutralization and durability of immunity. It is therefore imperative to define the composition of the humoral immune response elicited during EV-D68 infection.

Other enteroviruses, collectively called non-polio enteroviruses (NPEVs) are ubiquitous human pathogens. More than 110 NPEVs have been identified including echoviruses, Coxsackieviruses A and B (CAV and CVB), and EVs A and D (EV-A and EV-D). Infection with these small single-stranded (+) RNA viruses, particularly in children under the age of 6 years, can cause a broad-spectrum of serious illnesses including a polio-like childhood paralysis known as acute flaccid myelitis (AFM), neonatal sepsis, aseptic meningitis, myocarditis, hand-foot-mouth disease (HFMD), respiratory illness, and encephalitis.

The prevalence of NPEV-associated pathologies, such as neonatal sepsis, may be as high as 7 in 1000 live births. The Centers for Disease Control estimates that there are 10-15 million cases of HFMD annually. The NPEVs also include human rhinoviruses (HRVs), of which more than 160 genotypes have been identified. Development of severe respiratory complications, including pneumonia and bronchiolitis, especially in patients with chronic obstructive pulmonary disease, cystic fibrosis and asthma, are associated with infection by both HRV and EV-D68.  Biennial case surges led the NIH to declare AFM a global epidemic in 2019. These data illustrate the clinical importance of NPEVs and attest to their socioeconomic impact. It is therefore imperative to gain a better understanding of NPEV biology and the associated diseases.

To understand immunity against virus infection, an appreciation of the interactions between the virus particle and the antibody are a first step. How infections occur and lead to severe disease, and the role of systemic immunity must also be acknowledged. Unlike many other viral infections, resolution of NPEV infection by the host is thought to be highly dependent upon the humoral rather than the cellular immune response. Patients with X-linked agammaglobulinemia or common variable immunodeficiency are more susceptible to infection with EVs, including HRVs, and echoviruses. Furthermore, many immune deficient patients infected with echoviruses, particularly echovirus 11, develop severe disease including enteroviral associated meningoencephalitis. Moreover, an adult who was treated previously with monoclonal antibody therapy targeting the B-cell receptor CD20 developed meningoencephalitis and AFM after infection with EV-A71. These observations suggest that the presence of a protective systemic antibody response is critical for resolving infection. NPEVs enter the host via multiple routes including the respiratory and alimentary tracts, and the primary site of infection is thought to be within cells of the epithelial lining of the gut and respiratory tracts. The development of severe disease is linked to sites of secondary infection within the body such as the central nervous system and the heart. With the exception of poliovirus, we do not know how diverse NPEVs disseminate to secondary sites of infection. How antibodies and antiviral T cells may interrupt this process has also been understudied.

Our  laboratory is currently engaged in research to understand immune responses to NPEVs and their role in modulating disease outcomes.

AFM update July 2019

The Centers for Disease Control and Prevention has published ‘Surveillance for Acute Flaccid Myelitis – United States, 2018’ in Morbidity and Mortality Weekly Report (click for link to article). The article summarizes AFM for 2014-2018.

There were 233 confirmed cases of AFM in 2018, which is the largest number since surveillance for this condition began in 2014. AFM is defined as a disease of the nervous system – the brain and spinal cord – in which muscles and reflexes become weak, often accompanied by paralysis. Recently the definition has been modified to include MRI evidence of spinal lesions. The number of AFM cases have increased since 2014, mainly in young children. However, AFM is a rare disease, affecting 1-2 per million children each year.

Confirmed cases of AFM reported to CDC (n=559), United States, 2014-2018.

AFM is often called a ‘polio-like’ disease due to the paralysis that is observed in children with the disease. However, poliovirus is not found in the stool of children with AFM.

AFM was first defined in 2014 after reports of limb weakness in children across the US during an outbreak of respiratory disease caused by enterovirus D-68. AFM may also be associated with infections caused by other viruses, such as enterovirus A71, Coxsackievirus A16, West Nile virus and adenovirus. Since 2014 AFM surveillance has been conducted across the US.

Of the 233 patients with confirmed AFM in 2018, EV-D68 was the most frequently detected virus, mainly in respiratory samples. Only two samples of cerebrospinal fluid were positive: one for EV-D68 and one for EV-A71.

While it seems likely that EV-D68 is an etiological agent of AFM,  additional proof is clearly needed. Such proof would include showing that EV-D68 causes similar clinical disease in animal models following respiratory infection. These experiments have not been done but are a focus of our research.



Update on AFM cases in the US

As of this date in 2018, CDC reports 116 confirmed cases of AFM in 31 states. These 116 confirmed cases are among the total of 286 reports that CDC is investigating.

This map illustrates the number of confirmed cases of AFM in each state, demonstrating the nationwide nature of this outbreak:

afm-state-map

This graph displays the number of confirmed cases of AFM in the US:

CDC has established an AFM task force to encourage collaborations between CDC and the scientific community so that we can better understand the cause of AFM, how to prevent it, and how to treat it. More information on the task force can be found at this link. The first meeting of the task force will be on 4 December in Atlanta, GA.

Our laboratory has joined the AFM Consortium to bring together clinicians and basic scientists working on AFM.

Acute flaccid myelitis outbreak

There is currently an increase in the number of children in the US diagnosed with acute flaccid myelitis (AFM). This condition involves weakness of the arms and legs and may include other symptoms such as inability to breathe. The CDC has a complete definition of AFM at their website.

Cases of AFM in the US and Europe began to increase in 2014. The reason for this increase is not known. It has been suggested that enterovirus D-68 was responsible for the increased AFM observed in 2014 and 2016. This conclusion is based upon detection of EV-D68 genetic material (RNA) in the respiratory tract of children with AFM.

So far in 2018 there have been 72 confirmed cases of AFM in the US out of 191 suspected in 24 states. CDC indicates that the cause of most of these cases is unknown. Certain state health departments, such as New York and Colorado, are reporting detection of EV-D68 RNA from the respiratory tract of  some children with AFM.

A second enterovirus, EV-A71, has been isolated from some of the AFM children in Colorado. This virus is different from EV-D68 and infects the intestine rather than the respiratory tract. EV-A71 causes a rash called hand, foot, and mouth disease. It is known to be shed in feces, is present in the blood (viremia) and may cause neurological disease. In contrast, EV-D68 is not found in the blood or feces. EV-D68 is very unstable in the acidic environment of the stomach and should not be found in the feces. EV-A71, like poliovirus, is stable in the stomach and can be passed in the feces where it is spread to others.

Currently news sources are reporting that some doctors claim that EV-D68 is causing the outbreak of AFM in the US. Some doctors are testing for the presence of the virus in the feces, which is incorrect because, as stated above, the virus cannot pass through the stomach without being destroyed.

EV-D68 is unusual in its apparent ability to move from the respiratory tract to the nervous system. Our laboratory is interested in understanding this mode of virus spread. One way that we are studying the virus is by using three-dimensional lung and brain cultures produced from induced stem cells.
